VIZIO M470NV/M550NV User Manual
Connecting a Computer
RGB (VGA)
AUDIO
1
.
2
.
3.
4.
5.
6
.
RGB PC
RGB PC
Set computer to a resolution supported by your HDTV (see Preset PC Resolutions on page 61). If
your computer supports it, we recommend 1920x1080.
Turn off the power to your HDTV and computer.
Connect the RGB (VGA) cable from your computer to the RGB PC jack on of your HDTV.
Connect the 1/8-inch audio cable from your computer to the RGB PC Audio jack on your HDTV.
This step is optional and only needed if you want to transmit audio from the computer through the
TV.
Turn on the power to your HDTV and computer.
Select RGB (VGA) using the INPUT button on the remote control or side of the TV.
Note: Refer to your PC computer user manual for more information about the video output requirements.
Using HOMI
1
.
2
.
3.
4.
5.
Turn off your HDTV and computer.
Connect a HDMI cable to the HDMI output of your computer and the other end to the HDM11,2,
3, or HDMI SIDE jack on your HDTV.
Connect the 1/8-inch audio cable from your computer to the RGB PC Audio jack on your HDTV.
This step is optional and only needed if you want to transmit audio from the computer through the
TV.
Turn on the power to your HDTV and your computer.
Select HDMI-1, HDMI-2, HDMI-3, or HDMI SIDE using the INPUT button on the remote control or
side of the TV.
Version 6/28/2010
29
