VIZIO M470NV/M550NV User Manual
Connecting Your Cable or Satellite Box
Using HOMI (Best)
1 1
] O o |
Cable/Satellite Box
Cable and Satellite Boxes that have a HDMI digital interface should be connected using HDMI for optimal
results. To maintain image quality, use a VIZIO certified HDMI cable. This cable is available in 6, 15, and
30 foot lengths. Visit
1
.
2
.
3.
4.
Turn off your HDTV and Cable/Satellite box.
Connect an HDMI cable to the HDMI output of your Cable/Satellite box and the other end to the
HDM11,2,3, or HDMI SIDE jack on your HDTV.
Turn on the power to your HDTV and your Cable/Satellite box.
Select HDMI-1, HDMI-2, HDMI-3, or HDMI SIDE using the INPUT button on the remote control or
side of the TV.
The HDMI input on your HDTV supports High-bandwidth Digital Content Protection (HDCP).
HDCP encrypts the transmission between the video source and the digital display for added
security and protection.
Refer to your Cable/Satellite Set Top Box user manual for more information about the video
output requirements of the product or consult your Cable or Satellite operator.
HDMI Connections for Cable or Satellite Boxes with DVI
1 1
] O o |
Cable/Satellite Box
1. Turn off your HDTV and Cable/Satellite box.
2. Using a HDMI-DVI cable, connect the DVI end to your Cable/Satellite box and the HDMI end to
the HDM11,2,3, or HDMI SIDE jack on your HDTV.
3. Turn on the power to your HDTV and your Cable/Satellite box.
4. Select HDMI-1, HDMI-2, HDMI-3, or HDMI SIDE using the INPUT button on the remote control or
side of the TV.
There are no dedicated audio ports for HDMI so there may or may not be audio from the TV with
this connection.
Version 6/28/2010
23
