Operation
Legend™ 1200E Spot User Manual Rev. 03c -23-
Continued from previous page
Mode 1 (Cont.) Channel Function Value Percent/Setting
15
Gobo 2
(Cont.)
108  117
118  127
128  189
190  193
194  255
Gobo 11 shake
Gobo 12 shake
CCW rotation (fast~slow)
Stop
CW rotation (slow~ fast)
16 R-Gobo 2
000  127
128  189
190  193
194  255
Gobo indexing
CCW rotation (fast~slow)
Stop
CW rotation (slow~fast)
17 Focus 000  255 Narrow~wide
18 Zoom 000  255 15~30°
19 Effect/prism
000  025
026  050
051  076
077  101
102  127
128  255
Open
Effect 1
Effect 2
Effect 3
Effect 4
Effect Macro 1~24
20 R-Effect/Prism
000  127
128  189
190  193
194  255
Gobo indexing
CCW rotation (fast~slow)
Stop
CW rotation (slow~fast)
21 Iris 000  255 100~0%
22 Frost
000  179
180  201
202  223
224  245
246  255
0~100%
Open
 closed (fast~slow)
Closed  open (fast~slow)
Frost
Frost effect
23 Function
000  009
010  019
020  029
030  039
040  049
050  069
070  079
080  089
090  099
100  109
110  119
120  129
130  139
140  149
150  159
160  169
170  179
180  189
190  199
200  209
210  219
220  229
230  239
240  255
No function
Auto focus (enable)
Auto focus (disable)
Fan speed (auto)
Fan speed (high)
No function
Pan/tilt move-in-black (enable)
Pan/tilt move-in-black (disable)
Color move-in-black (enable)
Color move-in-black (disable)
Gobo move-in-black (enable)
Gobo move-in-black (disable)
Lamp On
Pan/tilt reset
Color reset
Gobo1/Gobo2/Iris reset
Shutter reset
Focus/zoom reset
Frost/effect reset
Reset all
Pan/tilt/color/gobo move-in-black (enable)
Pan/tilt/color/gobo move-in-black (disable)
Lamp off
No function
End of Mode 1
