Operation
-20- Legend™ 1200E Spot User Manual Rev. 03c
Continued from previous page
Factory Default
If you want to default the fixture to its factory configuration, follow the following steps:
1) Select Factory Settings.
3) Select Yes (default fixture) or No (exit without defaulting).
4) Press .
• The above operation will default all the fixture’s parameters to their original
factory configuration values.
• Defaulting the fixture does not affect the home position settings.
Offset Mode The Offset Mode provides fine adjustments for the home position of all the moving parts
in the optical path as well as the pan and tilt movements. The home position is where
the moving parts go when you reset them. In their corresponding home position, the
moving parts should not show any border or reduce the light output. If they do, use the
Offset Mode to fine adjust them.
Entering Offset
Mode
1) Press
2) Press for more than three seconds to enter the Offset Mode (the Offset
Mode menu will show).
4) Press
Pan Motor
1) Select Pan and press (a pop up window will open).
a) Select the new value (-128~127).
b) Accept the new value.
Tilt Motor
1) Select Tilt and press (a pop up window will open).
a) Select the new value (-128~127).
b) Accept the new value.
Shutter Motor
1) Select Shutter and press (a pop up window will open).
a) Select the new value (0~255).
b) Accept the new value.
Color Motor
1) Select Color 1 and press (a pop up window will open).
a) Select the new value (-128~127).
b) Accept the new value.
Cyan Dichroic Flag Motor
1) Select Cyan and press (a pop up window will open).
a) Select the new value (0~255).
b) Accept the new value.
Magenta Dichroic Flag
Motor
1) Select Magenta and press (a pop up window will open).
a) Select the new value (0~255).
b) Accept the new value.
Yellow Dichroic Flag
Motor
1) Select Yellow and press (a pop up window will open).
a) Select the new value (0~255).
b) Accept the new value.
3200 K Filter Dichroic Flag
Motor
1) Select 3200 K Filter and press (a pop up window will open).
a) Select the new value (0~255).
b) Accept the new value.
Gobo 1 Motor
1) Select Gobo 1 and press .
a) Select the new value (-128~127).
b) Accept the new value.
Continues on the next page
