Operation
Legend™ 1200E Spot User Manual Rev. 03c -17-
Continued from previous page
Lamp Off When DMX is
Absent
When enabled (Yes), this option turns the lamp off when DMX signal is absent.
1) Select Off if DMX Off.
2) Select Yes or No
3) Press .
Cooling Mode
This option determines the speed of the cooling fans, whether always high or
automatic.
1) Select Cooling Mode.
2) Select High or Auto.
3) Press .
Ignition Delay
When the State/Power On option is active, this setting configures the delay before the
lamp strikes after power on.
1) Select Ignition Delay.
2) Select the ignition delay in seconds (000 to 255).
3) Press .
Lamp Dousing
This option decreases the lamp power after the shutters/dimmers have been closed for
a configurable time to reduce the internal heat accumulation.
1) Select Low Power Delay.
3) Select the time delay in seconds (000~255).
4) Press .
Display Settings The options in the Display Settings section control the operation of the fixture’s LCD.
To access this section, do the following:
1) Press
2) Select Display Settings.
3) Select the corresponding function as indicated below.
4) Press
Display Reversal
This option reverses the LCD orientation (180º) to read it upright when the fixture is
hanging from a truss.
1) Select On/Off.
2) Select Yes or No.
3) Press .
Back Light Automatic Off
This option determines whether the LCD backlight will turn off automatically after 30
seconds of control panel inactivity.
1) Select Back Light Automatic Off.
2) Select Yes or No.
3) Press .
Back Light Intensity
This option selects the intensity of the LCD backlight.
1) Select Back Light Intensity.
2) Select 1~10.
3) Press .
Temperature Unit
When enabled (Yes), this option turns the lamp on when DMX signal is present.
1) Select On if DMX On.
2) Select ºC (Celsius) or ºF (Fahrenheit).
3) Press .
Continues on the next page
