STEM QUICK-CONNECT GUIDE
STEP 7 - Connecting a DVD/LD Player or Dolby Digital LD Player
Connecting a DVD/CD Player (using its
digital output)
Connect a DVD or CD player with a digital output to
the VIDEO 2 (coaxial) or VIDEO 3 (optical) Dolby
Digital/PCM INPUT according to the diagram on
the right.
Connect its video outputs to the corresponding
video inputs as shown in the diagram in STEP 6 -
Connecting Video Components.
NOTE: If you re using the DVD or CD player’s digi­
tal output, it Is not necessary to connect its 2-chan­
nel analog outputs.
Connecting a Dolby Digital LD Player
Connect a Dolby Digital LD players AC-3 RF output to
an RF demodulator such as the Kenwood DEM-9991D
(sold separately). Connect the RF demodulators digital
output to the VIDEO 2 Dolby Digital/PCM input accord­
ing to the diagram on the right.
Connect the LD player’s video and 2-channel
analog outputs to the corresponding VIDEO 2
inputs as shown in the diagram in STEP 6 -
Connecting Video Components.
NOTE: Do not connect the LD players AC-3 RF
output directly to the receiver.
VR-209 RECEIVER
©
© E O 0 ©0© © E3
©
O
©
© ©©
©© ©© © ©i©i©idb
© © ©i©iq fe
© 0 ©
• or
DOLBVDIGiTAL.PCMIN
VIDEO 2 ■ VIDEO 3
COAX-AL CIGrAL
OUTiAUDiOi
CPT'CAL DIGITA
OUT AUDOi
DVD PLAYER* or DVD PLAYER** or
CD PLAYER* (with CD PLAYER** (with
COAXIAL DIGITAL OUT) OPTICAL DIGITAL OUT)
'Connect video/audio cables "Connect video/audio cables
to VIDEO 2 jacks to VIDEO 3 jacks
DEM-9991D
OC nCMnni 11 ATAD
DOLBY DIGITAL
COAXIAL OOrAL
OUTiAUOlCi
nr UtlVIUUULAI UM
(optional)
GJT
■A-JDIO;
LD PLAYER
QUESTIONS ABOUT YOUR NEW SYSTEM?
if you have any questions about your new system,
please contact our Stage 3 Customer Service
Department on any business day at:
• (310) 639-5300 from 8:30
a , m . to 5:00
p . m .,
Pacific Time
Or visit out website anytime at:
• www.kenwoodusa.com
