Cabletron Systems MMAC-Plus 9T122-24 - Manual (Page 7)

Introduction
1-2
Management Information Base (MIB) Support
The 9T122-24 module provides MIB support including:
• IETF MIB II (RFC 1213)
• IETF RMON MIB (RFC 1271 and 1513)
• IETF Bridge MIBs (RFC 1493 and 1525)
• IEEE 802.5 Token Ring MIB (RFC 1231)
• Cabletron Enterprise MIBs
Ring Security
This feature prevents unauthorized stations from attaching to the ring. Using
Local or Remote Management, the module may be configured as to which MAC
addresses are allowed to operate on the ring.
Multi-Ring Out Capability
With this feature any port of the module may be configured as a ring-out port
through management software. In this configuration a stand-alone passive
concentrator (such as an IBM 8228 MAU) may be added to the ring.
Telnet
A telnet session can be set up with the module to provide access to the Local
Management screens.
LANVIEW LEDs
The 9T122-24 use LANVIEW – the Cabletron Systems built-in visual diagnostic
and status monitoring system. With LANVIEW LEDs, you can quickly identify
the device, port, and physical layer status at a glance.
Hot Swapping
The 9T122-24 can be installed or removed from the chassis while the MMAC-Plus
is powered up without affecting the operation of the remaining modules in the
chassis.
For a complete list of supported MIBs, refer to the release notes provided in
the module package.
NOTE
