Installation
2-6
See the Cautions at the end of this table.
Table 2-1. Function of DIP Switch
Switch Function Description
8
Clear
Password
1
When toggled, this switch clears user-entered
passwords stored in NVRAM, and restores the
default passwords. Once reset you can use the
defaults or enter new passwords.
7
Clear
NVRAM
2
The module uses NVRAM to store user
entered parameters such as IP addresses,
device name, etc. To reset these parameters to
the factory defaults, toggle this switch. Once
reset you can use the defaults or enter new
parameters which are stored in NVRAM when
the module is powered down, and remain
there until the switch is toggled again.
6
Force BootP
Download
Toggling this switch after pulling the board
out of the MMAC-Plus, clears download
information from NVRAM and forces image
files to be downloaded from the station
configured to act as that modules’ BOOTP
server.
5 Reserved For Factory Use Only
4 Reserved For Factory Use Only
3 Reserved For Factory Use Only
2 Reserved For Factory Use Only
1
Ring
Configuration
Off= One ring of 24 ports (factory default)
On = two rings of 12 ports each
1. Caution: Do not toggle Switch 8 unless you intend to reset the user
configured passwords to their factory default settings.
2. Caution: Do not toggle Switch 7 unless you intend to reset the user
parameters to the factory default settings.
!
CAUTION
