VIZIO M190MV/M220MV User Manual
Using Component Video (Better)
I
!
o
1 1
] Oo|
Cable/Satellite Box
Pb
o
Pr
o
L R
1.
Turn off your HDTV and Cable/Satellite Box.
2.
Connect the component cables (green, blue, and red) from your Cable/Satellite Box
to the COMPONENT jacks on your HDTV.
3.
Connect the audio cables (white and red) from your Cable/Satellite Box to the
COMPONENT L and R Audio jacks on your HDTV.
4.
Turn on your HDTV and Cable/Satellite Box.
5.
Select Comp using the INPUT button on the remote control, or directly by pressing
the COMP button on the remote control.
Using S-Video (Better)
O
R
n
©
L R
1 1
] Oo|
Cable/Satellite Box
1. Turn off your HDTV and Cable/Satellite Box.
2. Connect the S-VIDEC cable from your Cable/Satellite Box to the S-VIDEO jack on your
HDTV.
3. Connect the audio cables (white and red) on your Cable/Satellite Box to the
corresponding L and R AUDIO jacks on your HDTV.
4. Turn on your HDTV and Cable/Satellite Box.
5. Select AV using the INPUT button on the remote control, or directly by pressing the AV
button on the remote control.
Version 1/26/2010
19
