5. INSTALLATION
Stick the guide pattern on the wall or ceiling.
Drill four holes according to the guide pattern then
insert anchors into the drilled holes.
O Draw out power / video wires to the connecting places.
O Fixed the camera to a celling using four screws.
Adjust desired focus and scene by turning and moving
the 3-axis camera bracket by hand.
O Put the dome cover over the base.
O Fix the dome cover on the base by covering.
Guide Pattern
Dome Base
iiir
Mounting
Screw
A
Dome Cover
NOTE
^ Insert coin to the side hole and
remove the dome cover by twist coin.
<
