Kenmore TRIO 795.7757 - Manual (Page 25)

USING YOUR REFRIGERATOR
DURABASE
1. To remove the Durábase, push it back to the end as
much as possible. Tilt up the front of the Durábase and
pull straight out.
2. To install, insert the Durábase in rail assembly.
PULL OUT DRAWER
To separate the drawer, push the front left and right hooks
in 0 direction to pull up and remove.
Then gently lift the gear part of rear left and right side of
the drawer and pull it out in 0 direction.
DURABASE DIVIDER
The Durábase divider allows you to organize the
Durábase area into sections.
To install, reposition the gear part of rear left and right
side of the drawer after pulling out both rails as much as
possible, and gently push down both left and right side
while checking the hook on the front part.
1. To remove, pull divider staight up.
2. To install, hook top corners of divider over top edge of
durábase.
A WARNING: When the divider of the freezer drawer is
removed, children may crawl inside.
25
