Temperature Options without a Temperature Controller
A WARNING
Do not adjust the other dip switches uniess specificaiiy
instructed to do so.
The default temperature setting for this appliance
installed without a remote controller is 120° F (49° C). If
desired the temperature setting can be changed to 140°
F (60° C) by adjustment of a dip switch. Set dip switch
5 to ON to obtain 140° F water temperature setting.
Set dip switch 5 to OFF (default) to obtain 120° F water
temperature setting.
Temperature Ranges
120° F (49° C) 140° F (60° C)
Figure 12
This water heater will attempt to provide hot water at the temperature setting even when the water flow is varied or
when more than 1 tap is in use. The water heater can deliver water at only one temperature setting at a time. The
available temperatures for a given model are provided below.
Table 8:
Model Temperature Settings Available (°F)
305 Series 98 100 102 104 106 108 110 115 120 125* 130* 135* 140*
505 Series 98 100 102 104 106 108 110 115 120 125* 130* 135* 140*
Temp, in Celsius 37 38 39 40 41 42 43 46 49 52 54 57 60
* Re-setting the Maximum Temperature
Temperature settings from 125-140 °F (52-60 °C) are available by setting dip switch 6 to ON in the SW1 bank of 8
dip switches.
Table 9:
Suggested temperatures are: These temperatures are suggestions only.
Kitchen 120°F (49°C) A temperature lower than 98°F (37°C) can be obtained
at the tap by mixing with cold water.
Shower 98°- 110°F (37° - 43°C)
To change the temperature scale from Celsius to Fahrenheit or visa versa, press and hold the “On/Off” button for 5
seconds while the water heater is OFF.
Setting Controller to Mute
To eliminate the beeps when keys are pressed or to turn the beeps back on, press and hold both the A and T
buttons until a beep is heard (approximately 5 seconds).
