Control Pad Features
Note: The appearance of your oven control may differ slightly from the one illustrated below. However, all functions
are the same. Also, push buttons or pads may be shaped differently than those appearing in this Use and
Care Guide.
READ THE INSTRUCTIONS CAREFULLY BEFORE USING THE OVEN. For satisfactory use of your oven, become
familiar with the various functions of the oven as described below.
OVEN CLOCK SET COOKTME UP and DOWN ARROWS PADS Used BAKE PAD—
INTERiOR PAD Used to PAD Used to afong with the function pads to seiect Used to select
LIGHT PAD set the time enter the length oven temperature, cook time, start time the bake
Used to turn of day. of the baking (when programming an automatic start function,
oven interior light \ time. \ time), time of day, clean time and
ON and OFF________ \ \ minute timer.
FEATURE
INDICATOR
LIGHTS— These
light to show which
feature is in use.
TIMER SET/OFF PAD
Used
to set or cancel
the minute timer. The
minute timer does not
start or stop cooking
Aiso, TIMER SET/OFF
Pad
is used to set the
Continuous Bake
Feature.
SELECT CLEAN
PAD (some models)
Used
to select the
Self-Cleaning cycle.
A 2, 3 or 4 hour
SeSf-
Clean time may be
seiected (some
models).
DELAY START PAD Used to set the
desired start time for baking. May be
used with COOK TIME to program a
delayed bake cycle or a delayed clean
cycle.
BROIL PAD—
Used
to select
the variable broil
function.
^^^———
WARM & HOLD
PAD— Used to
set the Warm &
Hold feature. i
OVEN, PREHEAT & DOOR LOCK (some models)
LIGHTS* The “Oven” light wii! glow each time the oven
unit turns on to maintain the set oven temperature. The
“Preheat” light will glow when the oven is first set to
operate, or if the desired temperature is reset higher than
the actual oven temperature. The “Door Locked” light wili
flash until the door locks when the self-clean cycle is in use.
It glows constantiy after the door locks (some models).
STOP CLEAR PAD— Used to
clear any function previously
entered except the time of day
and minute timer. Press STOP
CLEAR to stop cooking. Also the
STOP CLEAR pad Is used to
activate oven lockout setting,
(some models).
‘Note: The OVEN indicator light on the electronic display will turn ON and OFF when using the Bake feature and
during preheat. This is normal and indicates that the oven is cycling to maintain the selected baking temperature.
When preheat indicator light turns OFF, your oven is ready.
For a slient control panel:
When choosing a function, a beep will be heard each time a pad is pressed. If desired, the control can be programmed
for silent operation.
1. To tell if your oven is set for normal or silent operation press and hold for 7 seconds. - " or "SP" (speaker)
appears in the display.
2. Within 5 seconds, press the or v pad to switch between normal sound operation and silent operation mode.
The display will show either - " or "SP".
3. Wait 5 seconds to return to normal operating mode.
If "SP" appears, the control will operate with normal sounds and beeps. If "- - " appears, the control is in the silent
operation mode.
Temperature Conversion (Fahrenheit / Celsius)
The electronic oven control is set to operate in “F (Fahrenheit) when shipped from the factory. The oven can be
programmed for any temperature from 170“F to 550“F (77“C to 288°C).
To change the temperature to °C (Celsius) or from °C to °F (contro! should not be in a Bake or Clean mode):
1. Press and hold for 7 seconds until °F or °C appears in the display.
2. Press the yv or pad to change °F to °C or °C to °F.
3. Wait 5 seconds to accept the changes or press to reject the changes.
