REPAIR PARTS FOR WATER SOFTENER
Kenmore MODEL NOS. 625.388260 and 625.388270
A. WATER SOFTENER COMPLETE
KEY
NO.
PART
NUMBER
DESCRIPTION
1 —
Cover Lock (req’d for ship, only)
1 — Rim Insert (req’d for shipping only)
2 7230020 Cover (main)
3 7229998 Salt Hole Cover
4 7252373 Transformer. 24V-1 OVA •
5 7249532 Timer Repl. (PWA), UltraSoft 250
- 7255737 Timer Repl. (PWA), UltraSoft 275
6 7230038 Faceplate (order following decal)
- 7247417 Faceplate Decal, UltraSoft 250
-
7253133 Faceplate Decal, UltraSoft 275
7 7231571 Rim
8 7232080 Brinewell Cover
9 7082150 Wing Nut, 1/4"
10 7100819 Brinewell
11 7137913 Decal, Salt Level ®
12 7257307 Salt Storage Tank
13 7232250 Plastic Screw, 1/4"x5/8"
14 0900431 Tube Clamp •
15 1103200 Tube Adaptor •
16 9003500 Grommet •
17 7116488 Brine Valve Asm. (also see pages 6-3, 6-4)
18 7105047 Replacement Distributor
19 0502272 Resin
20 7144952 Resin Tank, UltraSoft 250 (incl. Key No. 19)
—
7235478 Resin Tank, UltraSoft 275 (incl. Key No. 19)
21 7170270 0-Ring, 2-3/4" X 3”
22 7077870 Top Distributor
23 7170254 O-Ring, 13/16" X 1-1/16"
24 7170296 0-Ring, 2-7/8" X 3-1/4"
25 7141001 Vapor Barrier
26 7176292 Clamp Section (2 req.)
27 7088033 Clamp Retainer (2 req.)
28 7003847 O-Ring
♦ 3442699 Resin Bed Cleaner
♦ 7144821 Parts Bag, (includes parts marked with a •,
pages 6-2, 6-4 & 6-6) - order manuals
separtately if needed.
♦ 7258997 Installation Manual
♦ 7259024 Owners Manual
♦ not illustrated.
® Aligns with top of brinewell.
• included in parts bag.
