Generac NP-50LPG Recreational Vehicle Generator
REPAIR PARTS - ALTERNATOR AND PANEL
Drawing No. 94106
ITEM
DESCRIPTION
PART NO.
QTY.
ITEM
DESCRIPTION
PART NO.
QT
1
Lower Bearing Carrier
75995
1
36
Vibration M ount
82737
4
2
50 Rotor Assembly
92605H
1
37
M 6-1.0 Hex Nut
49813
4
3
50 Stator Assembly
92604H
1
38
M 5-0.8
X
16 Capscrew
55440
1
4
Ball Bearing
73159
1
39
M 3 Lock W asher
43182
2
5
Ball Bearing
31971
1
40
M 5 Special Lock W asher
A8475
1
6
Upper Bearing Carrier
72379B
1
41
2.5A.-ON Circuit Breaker
53623
1
7
Stator Stud
77006
4
42
M 5 Shakeproof W asher
22769
1
8
M 8-1.25 Flange Lock Nut
52858
8
43
Regulator Voltage
83049
1
9
Brush Holder
66386
1
44
M 5 Lock W asher
22152
6
10
M 5-0.8
X
16 Taptite
66849
2
45
M 5-0.8 Hex Nut
51716
4
11
Nylon W asher
27756
4
46
20A. Circuit Breaker
90144
1
12
Generator Top Housing
86314
1
47
30A All Units Cir. Breaker
90145
1
13
Resistor
75234
1
48
#6-32 w/Lockwasher Screw
25105
4
14
M 6 Flat W asher
22473
3
49
Panel Cover
86315
1
15
M 6 Lock W asher
22097
5
50
M 4-0.7
X
16 Screw w/Lock
90734
4
16
M 6-1.0
X
60 Capscrew
74095
1
W asher & Flat W asher
17
Ground Cable
90141
2
51
M 4 Flat W asher
22985
1
18
Shakeproof Lock W asher
22447
1
52
Fuse Holder
32300
1
19
M 6-1.0
X
20 Taptite
74906
4
53
15A. AGC Fuse
22676
1
20
P.C.B. Controller
94039
1
54
6A (Start/Stop) S.P.D.T.
87798
1
21
Starter Cable
10-74260
1
Switch
22
5/16 Lock W asher
22129
2
55
S.P.D.T. Switch (Fuel Pump)
92113
1
23
5/16-18 Hex Nut
22259
2
56
Terminal Block
75210A
1
24
Panel Sheet M etal
86316
1
57
M 4 Shakeproof W asher
23365
1
25
4-Pin Connector
53650
1
58
M 4-0.7 Hex Nut
51715
1
26
Connector
91915
1
59
30A. CB Rating Decal
90157
1
27
Remote Harness
75244
1
60
20A. CB Rating Decal
90156
1
28
M 6-1.0
X
12mm Capscrew
66476
2
61
Cust. Connection Decal
89438A
1
w/Lock W asher
62
Hose Clamp
31791
1
29
Starter Contactor
86729
1
63
M 5 Flat W asher
23365
1
30
M 4-0.7
X
16 Capscrew
75476
3
64
M 5
X
10 Taptite
74908
2
31
M 4 Lock W asher
22264
4
65
Bushing
23484S
1
32
Battery Charge Rectifier
65795
1
66
Battery Cable Boot
75763A
1
33
M 3-0.5
X
15 Capscrew
90987
2
67
Plastic Spacer
94070
1
34
Panel Support Bracket
86317A
1
68
M 6-0.8X 110PPHM S.
94071
1
35
M 5-0.8
X
30 Capscrew
75235
*3
69
M 5 Flat W asher
51713
2
R e c r e a t i o n a l V e h i c l e G e n e r a t o r
