Generac NP-50LPG Recreational Vehicle Generator

ELECTRICAL DATA

Drawing No. 94210

BATTERY

LEGEND

BCR - BATTERY CHARGE RECTIFIER
CBl - CIRCUIT BREAKER. 30A
CB2 - CIRCUIT BREAKER. 20A

CB3 - CIRCUIT BREAKER. 2.5A

- CHOKE HEATER (GASOLINE MODELS ONLY)
- CHOKE SOLENOID (GASOLINE MODELS

QNL'O

- FUSE, 15A

- FUEL PUMP-DR-LPG SHUT OFF VALVE

- TERMINAL, GROUND 4-TAB
- ^€TER. HOUR (OPTIONAL)

- SWITCH. HIGH TEMP. OIL (CLOSES ON HIGH TEMP.)

- IGNITION MAGNETO

- LIGHT. RUN (OPTIONAL)

- SWITCH, LOW OIL PRESSURE (CLOSES ON LOW PRESSURE)

PCB - ENGINE CONTROLLER
R1 - RESISTOR, 1 OHM 25W

STARTER CONTACTOR
STARTER MOTOR

SWITCH. START/STOP

SWITCH FUEL PRIMER

SPARK PLUG »1 CYL.

TERMINAL, CONN. 4-TAB

CONNECTOR

-NEUTRAL CDNNECTION

BY CUSTOMER

R e c r e a t i o n a l V e h i c l e G e n e r a t o r
