Generac NP-50LPG Recreational Vehicle Generator
REPAIR PARTS - BASE AND PULLEYS
Drawing No. 95865
ITEM
DESCRIPTION
PART NO.
QTY.
ITEM
DESCRIPTION
PART NO.
QTY.
1
BASE, M OUNTING
92603
1
35
COVER PLATE, EXH. BASE
92203
1
2
GROUND CABLE
90141
1
36
ADAPTOR, UNIVERSAL EXH.
91146
1
3
M OUNT, (RUBBER)
46911
4
41
CLAM P, EXH. PIPE-1-1/4 DIA.
96289
1
4
CAPSCREW , .-3/8"-16
X
1/2“
25017
8
42
HHCS & LOCK W ASH-M 6-1DX16, ,79246
8
5
LOCKW ASHER-M 10
46526
10
43
GASKET, EXH. PIPE
77643
2
6
LOCKW ASHER-M 8
22129
4
44
FOAM TÁPE
29289
10FT.
7
SKID, RUBBER M OUNT
72391
2
45
LUG, GROUNDING
62684
1
8
SAFEW BOLT 5/16"-18x 3 1/2"
77603
2
46
W ASHER, SPRING RETAINER
75237
4
9
NUT, HEX-5/16-18
22259
2
47
COVER, AIR OPENING
75226
1
10
NUT, FLANGED LOCK-M 8-1.25
52858
6
48
SCREW (CRIM PTITE) #10-24 x .5
56893
12
11
CAPSCR. -M 8-1.25X60M M
51730
2
49
GASKET, FOAM -SLIDE PAN
75229
1
12
SPRING, BELT TENSION
29459
2
50
PAN, SLIDE
75227
1
13
W ASHER, SPRING CNTR.
75215
2
51
FLAT W ASHER-M 6
22473
4
14
SLIDE (NYLON)
73146
4
52
COVER, EXHAUST OUTLET
72384-C
1
15
SUPPORT, NYLON SLIDE
75209
2
53
LOCKW ASHER, SHAKEPR.-M 6
22447
2
16
M ANIFOLD, EXHAUST
91032
1
57
NUT, FLANGE-5/16-18 (SPECIAL) 81105
2
17
GASKET,
EXHAUST M ANIFOLD
90239
1
58
DECAL, GROUND
67210A
1
18
CAPSCR.,-M 8-1.25x65 LG.
57636
2
59
SCREW , TAPTITE M 5-0.8 x 10.
74908
9
19
GASKET, COLLECTOR PAN
92645
1
60
SCREW , TAPTITE M 6-1.0x10
45756
5
20
COVER PLATE -EXTERNAL
90859
1
61
FLAT W ASHER-M 10
22131
1
21
PULLEY, ENGINE
75224-B
1
62
REGULATOR M OUNT .BRACK.
78864
1
22
PULLEY, ALT.
73106-B
1
63
REGULATOR
75211
1
23
BELT (POLY V 4D-40"
75216
1
64
FUEL SOLENOID 12VDC
A2666
1
24
W ASHER, PULLEY RETAINER
49451
1
65
45° STREET ELBOW -3/4"
25425
1
25
CAPSCR., HEX HD. 3/8“-24 x 1"
42633
1
66
STRAIGHT BARB. FIT.-1/2 x 3/8" 63463
1
26
GUIDE, BLOW ER HOUSING
77017
1
67
HOSE CLAM P-SIZE-#8
57822
1
27
CAPSCR., 3/8"-24x2"
A8250
1
68
FUEL HOSE-1/2" DIA. x 8.50"
74994
1
28
SCREW aAPTlTE)-M 6-1.00 x 20
74906
2
69
90 "STREET ELBOW -3/4"
26307
3
30
HOUSING, BLOW ER
72375
1
70
PIPE, NIPPLE-3/4" x3" LG
26881
1
31
SPACER, BLOW ER HOUSING
73185
1
71
M 6-1.0x30 CAP SCREW
38750
2
32
LOCKW ASHER, M 5
22152
1
72
M 6 LOCKW ASHER
22097
4
33
CAPSCR. -M 5-0.80 x 80M M
77682
1
73
M 6 HEX NUT
49813
4
34
SPRING, GENERATOR SET M T
75242
4
76
M 6x 16 HEX HD. CAPSCR.
47411
2
R e c r e a t i o n a l V e h i c l e G e n e r a t o r
21
