Installing the dram, Section b.3 – Cabletron Systems 6H258-17 User Manual
Page 55
Installing Optional High Speed Interface Modules
Switch Settings, Upgrades, and Installations
B-5
Figure B-3
Installing the DRAM
B.3
INSTALLING OPTIONAL HIGH SPEED INTERFACE MODULES
Figure B-4 shows the location of the two connectors for an optional High HSIM or VHSIM.
Depending on if an HSIM or VHSIM is installed, one or both connectors are used.
NOTE
Refer to the installation instructions for the optional HSIM or VHSIM in the associated
user’s guide.
1
2
SIMM
Alignment Notch
Clip
Clip
Connector
Teeth
Side Notch
Side Notch
Connector
2504-91
