Crestron CHV-TSTATRF infiNET™ Thermostat
LCD Display Elements (Continued)
# LCD DISPLAY
ELEMENT
DESCRIPTION
5 Fan icon Displayed at all times. Flashes if a
communication error occurs.
6 AUTO indicator Displayed when FAN setting is AUTO.
If this is not displayed, FAN is always ON.
7 OFF indicator Displayed when the system mode is Off.
8 HOLD indicator Displayed when the HOLD setting is active.
9 H, C, F & A indicators H – Displayed whenever a Heat Call is being
made.
C – Displayed whenever a Cool Call is being
made.
F – Displayed whenever a Fan Call is being
made.
A – Displayed whenever an Aux Heat Call is
being made.
1. For heat pump and dual-fuel systems, when you select Emergency Heat mode (by pressing and
releasing the MODE button when System mode is Heat) the display will show “EH” in place of the
ambient temperature for two seconds.
2. When the CHV-TSTATRF detects a low battery condition (approximately one month of battery life
remaining), the display will alternate “Lo” in place of the ambient temperature once per second.
Operations & Installation Guide – DOC. 6490A infiNET™ Thermostat: CHV-TSTATRF • 29
