Install properly...
1. Check the strength of the floor. It should hold the
weight of a fully loaded freezer,
2 Pick a safe place, Indoors, away from In­
flammables such as gasoline.
3, Allow 3 inches (7,5 cm] air space on top of freezer
for proper ventilation,
4, Allow at least an inch (2,5 cm) between the
freezer condenser, on the back of the unit, and
the wall,
5, Allow '/2 inch (1,25 cm) on each side of the freezer
for ease of installation,
6, If the freezer is to be against a wall, you might
want to leave extra space on the hinge side so the
door can be opened wider
7, The four bolts that held your freezer in the shipping
crate are designed to be the levelling legs. Screw
the legs far enough into the bolt holes, in each of
the four bottom oorners, so the freezer stands
about 1 inch (2,5 cm) off the floor.
Level freezer...
so the door will stay
open at any position.
Levelling Leg
Lower Raise
Start adjustment with the door hinge side.
1, Slide freezer into place,
2, Adjust front legs to level the freezer,
- To raise front, turn each leg clockwise,
- To lower front, turn each leg counter-clockwise,
3, Check with level,
4, After freezer is fully loaded, recheck with level,
4
Remove sales labels...
Remove the Consumer Buy Guide label and any
inside labels before using the freezer.
To remove any remaining glue:
1, Rub briskly with thumb to make a ball, then
remove,
OR
2, Soak area with dishwashing detergent solution (1
teaspoon detergent in 1 quart warm water) be­
fore removing glue as described in step 1,
DO NOT USE rubbing alcohol or flammable or
toxic solvents, such as acetone, gasoline, car­
bon tetrachloride, etc. These can damage the
material.
NOTE: DO NOT REMOVE the Tech Sheet fas­
tened under the freezer at the front.
3-prong grounding
type wall receptacle
Freezer
Power Plug 3-prong
grounding plug
Recommended Grounding Method
A 115 Volt, 60 Hz,, AC only 15 or 20 ampere fused
and properly grounded electrioal supply is re­
quired, It is recommended that a separate cirouit
serving only this applianoe be provided.
Do not use an extension cord. Use a recep­
tacle which cannot be turned off with a switch
or pull chain. See individual electrical require­
ments and grounding instruction sheet in your liter­
ature package.
