Culligan Medallist Series ™ Water Conditioners with Timeclock or Soft-Minder ® Meter
Medallist Medallist Plus
8” Model 30 Model 45 Model 60 Model
Control Valve Type 3/4” 5-cycle Reinforced 1” 5-cycle Reinforced 1” 5-cycle Reinforced 1” 5-cycle Reinforced
Thermoplastic Thermoplastic Thermoplastic Thermoplastic
Overall Conditioner Height 51 in. 49 in. 63 in. 61 in.
1,295 mm 1,245 mm 1,600 mm 1549 mm
Media Tank Dimensions 8 x 44 in. 10 x 40 in. 10 x 54 in. 12 x 52 in.
(Dia. x Ht.) 203 x 1,118 mm 254 x 1,016 mm 254 x 1,372 mm 305 x 1,321 mm
Salt Storage Tank Dimensions 18 x 43 in. 18 x 43 in. 18 x 43 in. 18 x 43 in.
(Dia. x Ht.) 457 x 1,092 mm 457 x 1,092 mm 457 x 1,092 mm 457 x 1,092 mm
Exchange Media, Type & Quantity Cullex ® Media, 0.7 ft 3 Cullex Media, 1.0 ft 3 Cullex Media, 1.5 ft 3 Cullex Media, 2.0 ft 3
Underbedding, Type & Quantity Cullsan ® Underbedding, Cullsan Underbedding, Cullsan Underbedding, Cullsan Underbedding,
6 lb. 15 lb. 15 lb. 16 lb.
Exchange Capacity @ Salt 18,300 gr @ 4 lb. 18,200 gr @ 4 lb. 28,900 gr @ 6 lb. 32,600 gr @ 7 lb.
Dosage Per Recharge 1
25,100 gr @ 9 lb. 27,600 gr @ 8 lb. 38,900 gr @ 12 lb. 61,600 gr @ 18 lb.
27,500 gr @ 12 lb. 32,000 gr @ 12 lb. 46,800 gr @ 18 lb. 71,700 gr @ 30 lb.
Efficiency at Rated Salt Dosage 5 4 lb. salt dosage: 4 lb. salt dosage 6 lb. salt dosage 7 lb. salt dosage
4570 gr./lb. 4550 gr./lb. 4814 gr./lb. 4664 gr./lb.
Freeboard to Media 2 20.5 - 21.5 in. 13 in. 15 in. 16 in.
Freeboard to Underbedding 3 42.0 - 42.5 in. 35 in. 48 in. 46 in.
Salt Storage Capacity 250 lb. or 375 lb. 250 lb. or 375 lb. 375 lb. 375 lb.
Rated Service Flow @ Pressure Drop 5.9 gpm @ 12 psi 9.0 gpm @ 12 psi 9.6 gpm @ 15 psi 10.0 gpm @ 14 psi
Total Hardness, Maximum 75 gpg 75 gpg 99 gpg 99 gpg
Total Iron, Maximum (dissolved) 5 ppm 5 ppm 5 ppm 5 ppm
Hardness to Iron Ratio, Minimum 8 gpg to 1 ppm 8 gpg to 1 ppm 8 gpg to 1 ppm 8 gpg to 1 ppm
140 mg/L to 1 mg/L 140 mg/L to 1 mg/L 140 mg/L to 1 mg/L 140 mg/L to 1 mg/L
Operating Pressure 20 - 125 psi 20 - 125 psi 20 - 125 psi 20 - 125 psi
140 - 860 kPa 140 - 860 kPa 140 - 860 kPa 140 - 860 kPa
Operating Pressure (Canada) 20 - 90 psi 20 - 90 psi 20 - 90 psi 20 - 90 psi
140 - 620 kPa 140 - 620 kPa 140 - 620 kPa 140 - 620 kPa
Operating Temperature 33 - 120°F 33 - 120°F 33 - 120°F 33 - 120°F
1 - 50°C 1 - 50°C 1 - 50°C 1 - 50°C
Electrical Requirements 24V/60 Hz 24V/60 Hz 24V/60 Hz 24V/60 Hz
Electrical Power Consumption, 3 Watts/35 Watts 3 Watts/35 Watts 3 Watts/35 Watts 3 Watts/35 Watts
Min./Max.
Drain Flow, Maximum4
1.1 gpm 1.7 gpm 1.6 gpm 2.6 gpm
Recharge Time, Average 85 min. 64 min. 64 min. 52 min.
Recharge Water Consumption 23.3 gal. 36 gal. 46 gal. 51 gal.
1 Capacities and corresponding salt dosages pertain to low hardness waters. Capacities given per recharge
2 Measured from top of media to top of inlet fitting (backwashed and drained) for 8” tanks. Measured from top of media to top sur-
face of tank threads for 10” and 12” tanks.
3 Measured from top of underbedding to top of inlet fitting for 8” tanks. Measured from top of media to top surface of tank threads
for 10” and 12” tanks.
4 Backwash at 120 psi (830 kPa)
5 Efficiency rating only valid at stated salt dosage on softminder models and is efficiency rated according to NSF/ANSI Standard 44
2
Specifications
