O T H E R F E A T U R E S
Lint filters
Your washer has a self-cleaning lint filter (requires no cieaning by you) or a manual clean lint filter.
Check the shape of your agitator to see if you need to clean your lint filter.
AGITATOR ABOUT YOUR FILTER FILTER
Spiral-shaped agitator
MAGIC CLEAN® lint filter
This lint fiiter requires no cleaning. (The lint
fiiter at the bottom of the washer basket deans
itself.) During agitation, wash and rinse water
pass over the filter, separating the lint from the
water. The lint is then spun away from the filter
and out of the system during the spin part of
the cycle.
If your washer drains into a tub, remove any
lint collected in the tub or strainer.
MAGIC
CLEAN
lint filter Basket
interior
Fin Barrel-shaped
agitator
Manual clean lint filter
NOTE: If your agitator is barrel shaped with 5 fins at
the base, your filter requires no cieaning.
If your agitator is barrel shaped with 4 fins at the
base, your machine has a manual clean lint filter.
Clean the filter at the bottom of the agitator after
every load for best filtering results.
To clean:
1. Lift off the agitator barrel.
2. Wash or wipe the fiiter dean in the bottom of the
agitator barrel. The filter is not removable.
3. Replace agitator barrel. Snap it into piace.
Manual clean
lint filter
11
