Whirlpool EVISHEXP - Manual (Page 6)

Changing the light bulb...
Light Shield.
•
f
WARNING: To avoid possible shocks, first unplug
freezer or turn off electricity leading
to freezer at the main power supply.
1. Remove the light shield from the side of the control
panel. Depress the back of the shield to release the
tabs, then pull away
2. Replace bulb with a 40-watt appliance bulb.
3. Replace the light shield. Insert the shield tabs in the
slots, then press the shield to snap into place,
4. Plug in power cord or switch on eleotricity.
Removing the bottom basket...
To remove:
1, Lift front of basket out of supports,
2, Pull out.
Lift the Front,
Then Pull Out.
To replace:
1. Position back of basket on the rear wall supports
2. Lower front into place
The key eject lock...
can help reduce the hazard of child
entrapment
To lock or unlock the freezer you must hold the
key in the lock while turning The lock is spring
loaded so the key cannot be left in the lock
If the key is lost, contact your WHIRLPOOL
dealer for a replacement Always give the com­
plete model and serial number of your freezer
when requesting a replacement key.
The signal light...
automatically warns of any unexpected
power failure.
If the signal light is not glowing, immediately check:
• for power interruption,
• for an unplugged power cord,
• for a burned out signal light.
To replace burned out signal light:
1, Unplug power cord from outlet.
2. Open the freezer door.
3. Unplug burned out light and replace with one of
same wattage and size. Signal light can be
ordered from your WHIRLPOOL dealer.
Part No. 1103680
4, Close freezer door and plug power cord into outlet.
