USING YOUR RANGE
Replacing the storage drawer:
1. Fit ends of drawer slide rails into the
drawer guides on both sides of opening.
2. Lift drawer front and push in until metal
stops on drawer slide rails clear white
stops on drawer guides.
Lift drawer front
again to clear second stop and slide
drawer closed.
Drawer slide rail
The anti-tip bracket
The range will not tip during normal use. However, tipping can occur if you apply too much
force or weight to the open door without the anti-tip bracket properly secured.
AWARNING
Personal Injury Hazard
•To reduce risk of range tipping over, secure range with a properly
installed anti-tip bracket supplied with range or an optional wall-
mounted anti-tip bracket kit.
• If range is moved for cleaning or service, check that anti-tip device
is engaged before using range.
Failure to follow the above precautions could result in personal injury.
To verify the anti-tip bracket is
engaged (if you have a floor
bracket):
• Remove the storage drawer. (See page 19.)
• Look to see if the anti-tip bracket is attached
to floor with screws.
• Make sure one rear leveling leg is positioned
under the anti-tip bracket.
• See Installation Instructions for further details.
To verify the anti-tip bracket is
engaged (if you have a wall
bracket):
• Look to see if the anti-tip bracket is attached
with screws to the wall behind the control
panel.
• Make sure the cable on the back of the range
is secured by the two hooks on the bracket.
• Cable must be unhooked from wall bracket to
move range for cleaning or service. Recon­
nect cable before using range.
• See Installation Instructions for further details.
Rear leveling leg
