Lint screen
Pull straight
out.
The lint screen
s inside the dryer
drunn, on the
back wall. Clean
it before each
load.
A screen
blocked by lint
can increase
drying time.
1. Use the finger holes to pull the lint
screen straight out
2. Lightly squeeze the body, as
shown, while pulling the cover off
3. Roll lint off the
screen with
your fingers,
DO NOT rinse
or wash the
screen.
Wet
lint is hard to
remove
/
Squeeze body;
pull cover off.
Replace the cover on the body of
the lint screen
Push the lint screen straight back
In until it clicks into place
CAUTION: RUNNING THE DRYER WITH THE LINT SCREEN LOOSE,
DAMAGED OR MISSING CAN CAUSE OVERHEATING, DAMAGE TO
FABRICS AND DRYER PARTS, OR CREATE A
FIRE HAZARD.
Lint removal
Lint can gather inside the dryer and create a fire hazard.
This lint should be removed every 2 to 3 years, or more often,
depending on dryer usage. A qualified service person is
recommended for this job. •
• Unplug power supply cord.
• Moke sure dryer is cool.
• Metal edges may be sharp.
1. Remove back panel from dryer.
2. Avoid touching thermostats,
wires, terminals and heater box.
3. Remove lint from shaded area
- see art - with a soft brush or
vacuum cleaner.
4. Replace back panel. Recon­
nect, exhaust duct, etc.
Level the washer/dryer.
Exhaust Duct Outlet
Heaf Element Terminals
Heater Box
