For Model: CSP2761TQ0
(White)
UPPER CABINET AND FRONT PANEL PARTS
llus.
No.
Part
No.
DESCRIPTION
Illus.
No.
Part
No.
DESCRIPTION
Illus.
No.
Part
No.
DESCRIPTION
1
3390663
Screw, 10-16 x 1/2
28
3398948 Wire, Jumper
56
8529989 Harness
2
3391915
Screw, 10-16 x 1
29
3389627 Pulley (60 Hz.)
(Upper)
3
3391846
Clip, Front
30
3387610 Belt, Drive
56A
3390423 Plug, Multi-
Panel (2)
31
3390902 Clip, Door
Terminal
4
3393258
Screw, 10-16 x 1/2
Hinge (2)
56B
717252 Receptacle
5
3394881
Switch, Broken
32
3387118 Bracket, Motor
57
3390735 Seal, Door
Belt
33
693152 Bumper
58
3392538 Catch, Door
6
697773
Screw, 6-20 x 7/8
34
279731
4"-90°
Assembly
7
3978859
Cabinet (Upper)
Elbow
59
8066120 Lever, Snap
8
689172
Foot, Dryer
35
697750 Plug-Multivent
Switch
Plastic (2)
36
3392186 Washer
60
3392906 Handle, Door
9
660658
Clamp, Motor (2)
37
488729 Screw
61
697215 Panel, Toe
10
3387374
Spring, Idler
38
8283298 Jumper,
(Includes
11
3389420
Retainer, Idler
Door Switch
Illus. 33)
12
3392915
Gasket, Window
38A
717253 Plug, 2-Way
62
3389351
Top (Upper)
13
3388672
Pulley Assembly
38B
3936144 Connector
63
3391018 Tie, Cable
14
693995
Screw, 8-18 x 3/8
39
3388674 Bracket, Idler
64
63823 Cotter Pin
15
3392918
Window
40
343641
Screw, 10-16 x 1/2
65
3401797 Burner Assembly
(Not Shown Part
41
3406109 Door Switch
60 Hz.
3396122, Window
Assembly
(Refer To Pages
Pack. Includes
42
98129 Screw,
10 & 11 For
Illus. 12 & 15)
6-20 x 1 1/16
Breakdown)
16
3394081
Wire, Belt Switch
43
3389233 Bushing
66
3401775 Valve, Gas
17
8529757
Bracket, Burner
44
3387242 Seal, Front Panel
(Complete)
18
233520
Washer, Thrust
45
342055 Screw, 8-18 x 1/2
60 Hz.
19
297092
Clip (2)
46
3388229 Retainer
67
3387561
Clamp, Pipe
20
690997
Tri-Ring
47
3392905 Door, Rear
68
3393909 Screw, 8-32 x 7/8
21
3389247
Hinge And Pin (2)
48
694091
Screw, 8-18 x 3/8
69
686590 Ignitor
22
3392914
Frame, Window
49
3392880 Door, Front
70
3387057 Screw, 8-18 x 3/8
23
3979115
Bracket, Angle
50
718032 Screw, 8-18 x 3/4
24
3394331
Plate, Cover
51
3393081
Upper Front Panel
Optional Parts Not Included
(Bottom Exhaust)
52
696144 Stike, Door
25
3398948
Wire, Jumper
53
3400523 Screw, Security
26
3389249
Nut, "U" (4)
(Includes
Dryer Exhaust Kii
27
8538264
Motor Assembly
Illus. 64 )
(For Side & Bottom Venting)
60 Hz.
54
3393933 Fastener
55
3390647 Screw, 8-18 x 1/2
71
279818 White
FOR ORDERING INFORMATION REFER TO PARTS PRICE LIST
W10128962
