3401797 BURNER ASSEMBLY
For Model: CSP2761TQ0
(White)
USE WITH TYPE 1 - NATURAL, TYPE 2 - MIXED,
AND TYPE 4 - LIQUEFIED PROPANE AND BUTANE GASES
Illus. Part
No. No.
DESCRIPTION
1
3401797 Burner Assembly
2
688617
60 Hz.
(Type 1,2 & 3)
(White Rodgers)
Tube, Burner
3
694298 Bracket, Ignitor
4
686590 Ignitor
5
3393909 Screw & Washer
6
343641
(8-32 x 5/8)
Screw, 10-16 x 1/2
7
3389871
Base, Burner
8
3387057 Screw,
9
10
3397656
15775
3401775
10-16 x 1/2 (3)
Orifice, Burner
Type 1
Type 2
Valve, Gas
11
694421
60 Hz. (Complete)
Screw,
12
694538
8-32 x 1/2 (2)
Bracket, Coil
13
694540 Coil, 60 Hz.
14
694539
(2 Terminal)
(Main)
Coil, 60 Hz.
15
694424
(Split)
(3 Terminal)
(Pilot Position)
Leak, Limiter
16
694423 Screw, Regulator
17
694422
Adjustment
Spring, Regulator
20
239822 Plug, Pipe
21
3387224 Pipe, Gas Supply
22
697441
Valve & Union
23
3393767
Shut-Off
Pipe, Tail
24
233076 Nut, Compression
25
3387561
Clamp, Pipe
26
3389889 Bracket, Support
Following Parts Not Illustrated
694572 Conversion Kit
(Type 1 and 2)
to Type (4) L.P.G.
BA-133-A
FOR ORDERING INFORMATION REFER TO PARTS PRICE LIST
