USING YOUR REFRIGERATOR
To change crisper light
(on some models):
1. Disconnect refrigerator from power supply.
2. Pull top of light shield forward until it snaps
free.
3. Lower light shield to clear bottom supports.
4. Pull light shield straight out to remove.
5. Replace bulb with a 40-watt appliance
bulb.
6. Replace light shield in reverse order.
7. Reconnect refrigerator to power supply.
fZ/N^Crisper
light
To change the upper freezer light
(RS25AW only):
1. Disconnect refrigerator from power
supply.
2. Lift top of light shield up and pull shield
out.
3. Replace bulb with a 40-watt appliance
bulb.
4. Place light shield over bulb and snap
shield into place.
5. Reconnect refrigerator to power supply.
To change lower freezer light:
1. Disconnect refrigerator from power supply.
2. Push in sides of light shield until it snaps
free.
3. Replace bulb with a 40-watt appliance
bulb.
4. Replace light shield.
5. Reconnect refrigerator to power supply.
NOTE: Not all commercial appliance bulbs
will fit your refrigerator. Be sure to replace a
bulb with one of the same size and shape.
Freezer
light
