LATCH PARTS
For Models:GMC305PRB00, GMC305PRQ00, GMC305PRT00, GMC305PRS00
(Black)
(White) (Biscuit) (S.Steel)
17
18
Illus.
No.
Part
No.
DESCRIPTION
1
4451759 Vent, Exhaust
4449040 Screw
2
4451758 Seal, Foam
9
4450408 Baffle, Rear
4449154 Screw
10
9759525 Latch, Motorized
16
4452003 Blower
17
4455178 Vent, Top
18
4455177 Vent, Bottom
8186303
FOR ORDERING INFORMATION REFER TO PARTS PRICE LIST
