MICROWAVE DOOR PARTS
For Models:GMC305PRB00, GMC305PRQ00, GMC305PRT00, GMC305PRS00
(Black)
(White) (Biscuit) (S.Steel)
15
16
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
9
W10151072 Glass, Middle
15
Filler, Side
17
Glass, Outer
10
8303556 Frame, Door
4449083 Right Side
8303265 Black
4450038 Screw
4449086 Left Side
8303273 White
14
Bracket, Mounting
4449809 Screw
8303249 Black Stainless
4449141 Right Side
16
Handle, Door
8303279 Biscuit
4449142 Left Side
8302813 Black
24
8303169 Bracket, Handle
4449809 Screw
8302814 White
4451040 Screw
8302815 Biscuit
8303164 S.Steel
Illus. Part
No. No. DESCRIPTION
FOR ORDERING INFORMATION REFER TO PARTS PRICE LIST
10
8186303
