Whirlpool EH12OC EH15OC - Manual (Page 4)

Install properly...
I
Allow room to open lid
2 inches at back
J___
3 inches 3 Inches I
Remove sales labels...
Remove the Consumer Buy Guide label and any
inside labels before using the freezer.
To remove any remaining glue:
1, Rub briskly with thumb fo make a ball, then
remove.
OR
2. Soak area with dishwashing detergent solution (1
teaspoon detergent in 1 quart warm water) be­
fore removing glue as described in step 1.
DO NOT USE rubbing alcohol or flammable or
toxic solvents, such as acetone, gasoline, car­
bon tetrachloride, etc. These can damage the
material.
NOTE: DO NOT REMOVE the Care ft Service iabei
on inside iid or Tech Sheet on back of cabinet.
1 Check the strength of the floor. It should hold the
weight of a fully loaded freezer.
Pick a safe piace, indoors, away from in­
flammables such as gasoline.
Allow at least 3 inches (7.5 cm) air space on all
sides of freezer and 2 Inches (5 cm) at back. Leave
room at top for lid to open all the way.
It should not be necessary to remove the lid during
installation. If, for any reason, the hinges need ad­
justment, see your authorized WHIRLPOOL dealer.
Do not cover the freezer with Items such as
blankets, sheets, tablecloths, etc.
Level chest freezec..
from end to end and front to back so that the lid will
seal properly.
Check with level
Install defrost drain covec..
1. Remove cover from literature package.
2. Check drawing on front cover for placement.
3. Install cover.
DEFROST
DRAIN
Plug it in...
3-prong grounding
type wall receptacle
Retaining Clip
Freezer
Power Plug m | 3-prong
grounding plug
Recommended Grounding Method
A 115 Volt, 60 Hz., AC only 15 or 20 ampere fused
and properly grounded electrical supply is required.
It is recommended that a separate circuit sen/ing only
this appliance be provided.
Use a receptacle
which cannot be turned off with a switch or pull
chain. Do not use an extension cord.
Attach retaining clip over power cord plug from
literature package inside the freezer.
