UNIT PARTS
For Models: GI15NDXTQ0, GI15NDXTB0 ,GI15NDXTS0
Illus.
No.
Part
No.
DESCRIPTION
Illus.
No.
(White) (Black) (Stainle
Part
No. DESCRIPTION
ss Steel)
Illus.
No.
Part
No.
DESCRIPTION
1
2185532 Bracket, Fan Mtg.
13
489423 Screw
23
Drier
2
2185675 Pad, Foam
14
489472 Screw
2319826 Production
3
2188935 Blade, Fan
15
759112 Coil, Solenoid
4387019 Service
4
2315558 Motor & Mounting
16
2313806 Hot Gas Valve
24
2313624 Condenser
Plate Assembly
17
2187629 Wiring Harness,
25
1115375 Clip-Wiring
5
2310125 Wiring Harness,
Condenser Fan
26
2319835 Grommet-Cond.(1)
Complete Unit
18
Overload
27
2217397 Pad, Foam (2)
(Includes
2217223 Production
28
488500 Screw
Power Cord
4387938 Service
29
8281197 Screw
6
304392 Screw
(Includes Relay)
30
2217388 Base, Unit
7
2313858 Compressor
19
2155774 Strap
31
8281196 Screw
(Includes
20
Relay, Start
32 W10005420 Clamp-Nylon-Cable
Illus. 11,18,
2217224 Production
33
3400884 Screw
20,21 & 23)
4387938 Service
8
A201435 Clip, Mounting
(Includes
9
A201441 Shim (4)
Overload)
REFRIGERANT CHARGE
10
2185960 Clamp
21
Cover, Terminal
11
Grommet (4)
2208371 Production
2217318 Production
4387731 Service
6.5 OZ. (R134A)
4387558 Service
12
2208415 Tube, Process
