The Key Eject Lock...
can
help
reduce
the
hazard
of
child
entrapment.
To lock or unlock the freezer you must hold the
key in the lock while turning. The lock is spring
loaded so the key cannot be left in the lock.
If the key is lost, contactyour WHIRLPOOL dealer
for a replacement. Always give the complete
model and serial number of your freezer when
requesting a replacement key.
Changing Light Buib.
1. Unplug power cord.
2. Remove light shield by pulling away from the
side vvall.
3. Replace bulb with 40 watt appliance bulb.
4. To replace shield, insert tabs into slots in wall
and press.
Removing the Base Grille...
Lift grille off bottom supports.
• Open the door.
• Lift up on two tabs showing through grille.
• Swing the top of the grille forward.
• Replace in reverse order.
• Do not remove Tech Sheet fastened behind
the gri le.
Bottom Trivet...
To remove:
• Lift up, then pull out.
To repla :::e:
• Set in bottom of freezer.
• Push into place.
