1. Specifications
METRIC
EQUIVALENT
1.1. GL-X
WATER CONSUMPTION
PER RACK 1.7 GAL. 6.44 L
PER HOUR 40.8 GAL. 154.4 L
OPERATING CYCLE
WASH TIME-SEC 57 57
RINSE TIME-SEC 48 48
DWELL TIME-SEC 15 15
TOTAL CYCLE 2 MIN. 2 MIN.
OPERATING CAPACITY
RACKS PER HOUR 30 30
WASH TANK CAPACITY 1.7 GAL. 6.44 L
PUMP CAPACITY 35 GPM 132.5 LPM
WATER REQUIREMENTS 140°F 60°C
WATER INLET ½” 1.27 cm
DRAIN CONNECTION 1” 2.54 cm
CYCLE
TEMPERATURES(recommended) 140°F 60°C
WASH-°F (Min) 120°F 52°C
FRAME DIMENSIONS
DEPTH 24 3/4” 63 cm
WIDTH 24” 61 cm
HEIGHT (34 ¾”), with legs adjusted 39”-40 1/8” 99-102 cm
MAX CLEARANCE FOR GLASSES 11 ¼” 28.57cm
ELECTRICAL* 115 VAC
16 AMPS
SUSTAINER HEATER
(Not Booster Heater)
1.25 kW
WASH PUMP MOTOR 13.4 AMPS
*MUST CONNECT TO DEDICATED 20 AMP SUPPLY CIRCUIT.
COMPLIANCE WITH LOCAL ELECTRICAL CODES MUST BE FOLLOWED.
SHIPPING WEIGHT
GL-X (Approximate) 244# 110.6 kg
