6-2 Lighting
AUTO (Automatic): Turns the
headlamps on automatically at
normal brightness, together with the
following:
. Parking Lamps
. Taillamps
. Sidemarker Lamps
. License Plate Lamps
. Instrument Panel Lights
AUTO also controls the Daytime
Running Lamps (DRL). See
Daytime Running Lamps (DRL) on
page 6‑3.
;
(Parking Lamps): Turns the
parking lamps on together with the
following:
. Taillamps
. Sidemarker Lamps
. License Plate Lamps
. Instrument Panel Lights
A warning chime sounds if the driver
door is opened when the ignition
switch is off and the parking lamps
are on.
5 (Headlamps): Turns the
headlamps on together with the
lamps listed below.
. Parking Lamps
. Taillamps
. Sidemarker Lamps
. License Plate Lamps
. Instrument Panel Lights
A warning chime sounds if the driver
door is opened when the ignition
switch is off and the headlamps
are on.
#
(Front Fog Lamps): Turns the
fog lamps on or off. The fog lamps
come on together with the following:
. Parking Lamps
. Taillamps
. Sidemarker Lamps
. License Plate Lamps
. Instrument Panel Lights
See Front Fog Lamps on page 6‑5.
Headlamp High/
Low-Beam Changer
Push the turn signal/lane change
lever away from you and release, to
turn the high beams on. To return to
low beams, push the lever again or
pull it toward you and release.
This indicator light turns on in the
instrument panel cluster when the
high-beam headlamps are on.
