Black plate (31,1) Chevrolet Corvette Owner Manual - 2012
Instruments and Controls 5-31
Head-Up Display (HUD)
{
WARNING
If the HUD image is too bright,
or too high in your field of view, it
may take you more time to see
things you need to see when it is
dark outside. Be sure to keep the
HUD image dim and placed low in
your field of view.
For vehicles with the Head-Up
Display (HUD), you can see some
of the driver information that
appears on the instrument panel
cluster.
The information may be displayed in
English or metric units and appears
as an image focused out toward
the front of the vehicle. The HUD
consists of the following information:
. Speedometer
. Turn Signal Indicators
. High-Beam Indicator Symbol
. Tachometer
. Manual Paddle Shift Gear
Indicator (If Equipped)
These displays on the HUD are
for use when using the manual
paddle shift controls to shift the
transmission. See “Manual
Paddle Shift” in Automatic
Transmission on page 9‑27.
. Shift Light
This light is used for
performance driving to
indicate that the vehicle's best
performance level has been
reached to shift the transmission
into the next higher gear.
An arrow pointing up will light
up on the display just prior to
reaching the engine fuel cut-off
mode. This cut-off is about
6,500 rpm for the LS3 engine,
6,600 rpm for the LS9 & ZR1
engines, and 7,000 rpm for the
LS7 engine.
. Check Gauges Warning
. Engine Coolant Temperature
Gauge
. Transmission Fluid Temperature
Gauge, (Automatic Transmission
Vehicles Only)
. Engine Oil Temperature Gauge
. Engine Oil Pressure Gauge
. G-Force Gauge
. Boost Gauge (If Equipped)
. Audio Functions, Street
Mode Only
. Navigation, Only with Navigation
Radio, Turn-by-Turn Guidance.
Street Mode Only
