Service and Maintenance 11-13
Usage Fluid/Lubricant
Manual Transmission (V8 Engine) Manual Transmission Fluid (GM Part No. 88861800, in Canada 88861801).
Rear Axle (V6 Engine with Automatic
Transmission)
Rear Differential Fluid 75W-90 (GM Part No. 89021677, in
Canada 89021678).
Rear Axle (V6 Engine with Manual
Transmission)
Rear Differential Fluid 75W-90 Limited Slip (GM Part No. 89021677 and
Friction Modifier 1052358, in Canada 89021678 and Friction Modifier
992694).
Rear Axle (SS)
Rear Differential Fluid 75W-90 Limited Slip (GM Part No. 89021677 and
Friction Modifier 1052358, in Canada 89021678 and Friction Modifier
992694).
Rear Axle (ZL1)
Rear Differential Fluid Dextron LS Gear 75W-90 (GM Part No. 88862624,
in Canada 88862625).
Key Lock Cylinders
Multi-Purpose Lubricant, Superlube (GM Part No. 12346241, in
Canada 10953474).
Hood Latch Assembly, Secondary
Latch, Pivots, Spring Anchor, and
Release Pawl
Lubriplate Lubricant Aerosol (GM Part No. 89021668, in
Canada 89021674) or lubricant meeting requirements of NLGI #2,
Category LB or GC-LB.
Hood and Door Hinges
Multi-Purpose Lubricant, Superlube (GM Part No. 12346241, in
Canada 10953474).
Weatherstrip Conditioning
Weatherstrip Lubricant (GM Part No. 3634770, in Canada 10953518) or
Dielectric Silicone Grease (GM Part No. 12345579, in Canada 10953481).
