5
REV 6552520110516
ENGLISH 65525
(1) Fuel Tank – 1 .06 gallon (4 L) capacity fuel tank .
(2) Air Filter – Protects the engine by filtering dust
and debris from the intake air .
(3) Muffler
(4) 2” Outlet – 2” NPT outlet connector .
(5) Low Oil Sensor – Senses the level of oil in the
crankcase and shuts the engine down if the level
falls too low .
(6) Oil Filler Cap – Check and fill engine oil level .
(7) 2” Inlet – 2” NPT inlet connector .
(8) Throttle – Used to adjust engine speed .
(9) Choke lever– Used to start the engine .
(10) Fuel Valve
(11) Engine Switch – Used to start the engine .
(12) Recoil Starter – Used to start the engine .
Semi-Trash Pump
CONTROlS ANd fEATURES
4 1 2 3
7
11
9
8
12
10
6
5
Read this owner’s manual before operating your semi-trash pump . Familiarize yourself with the location and function
of the controls and features . Save this manual for future reference .
