Champion Power Equipment 65525 - Manual (Page 13)

REV 65525-20110516
10
65525 ENGLISH
Starting the Engine
1 . Make certain the semi-trash pump is on a flat, level
surface .
2 . Flip engine switch (A) to “ON” position .
3 . Rotate the fuel valve (B) to the “ON” position .
4 . Move the choke lever (C) to the “Choke” position .
5 . Pull the starter cord slowly until resistance is felt
and then pull rapidly .
6 . As engine warms up, move the choke lever (C) to “Run” .
7 . Move the throttle lever (D) to the “Fast” position .
Stopping the Engine
1 . Turn the ignition switch to the “Off” position .
2 . Rotate the fuel valve to the “Off” position .
3 . Allow the engine to cool thoroughly .
Remove the cap from the cooling pump chamber
and allow it drain completely .
Pump performance can be adjusted using the throttle .
To decrease pump output, slide the throttle to the right .
To increase it, slide the throttle to the left .
5 . Wrap the 2” NPT inlet clockwise with the Teflon
tape provided . Carefully thread the male connector
to the intake port .
6 . Attach the quick coupler to the male coupler and
lock in place with the cam lock .
7 . Attach the strainer to the intake hose and secure
with the hose clamp .
8 . Remove the cap from the pump chamber and
completely fill the chamber with clean water . Tighten
the cap .
OPERATION
If the engine starts but does not run make certain
that the semi-trash pump is on a flat, level surface .
The engine is equipped with a low oil sensor that
will prevent the engine from running when the oil
level falls below a critical threshold .
NOTE
Connecting a Host Kit Cont’d.
DO NOT run the pump dry .
Running the pump dry can destroy the pump seals
and will void the warranty . If the pump was running
while dry, stop the engine and allow it to cool
thoroughly before filling the chamber with water .
WARNING
A
b
d
C
