REV 65525-20110516
18
65525 ENGLISH Engine Parts list
# Part Number Description Qty
1 GB5789--86-FB6-8 Flange Bolt M6*8 5
2 160 .061100 .32 Recoil Starter Cover 1
3 ST160F--1061005 Recoil Starter Spring 1
4 ST160F--1061009 Recoil Starter Rope 1
5 ST160F--1061001-A Recoil Starter Reel 1
6 ST188F-1060006 Ratchet Spring 2
7 ST188F-1060005 Starter Ratchet (Metal) 2
8 ST188F-1060004 Ratchet Guide Spring 1
9 ST188F-1060003 Ratchet Guide 1
10 ST188F-1060002 Setting Screw 1
11 GB5789--86-FB6-12 Flange Bolt M6*12 11
12 ST168F--1080100-G Fan Cover Comp 1
13 ST168F-1070008-G Tube Clip 9 .5 1
14 ST160F--1061200 Recoil Starter Knob 1
15 ST160F--1050010 Nut M14 1
16 ST160F--1060001 Start Hub 1
17 ST168F--1080001 Cooling Fan 1
18 ST168F--1120100 Fly Wheel 1
19 ST168F--1030100 Oil Seal 2
20 ST160F--1110108 Governor Washer 2
21 ST160F--1110101 Governor Weight Holder 1
22 ST160F--1110102 Governor Weight Pin 2
23 ST160F--1110104 Governor Shaft 1
24 ST160F--1110103 Governor Holder Clip 1
25 ST160F--1110107 Governor Weight 2
26 ST160F--1110106 Governor Shaft Washer 1
27 ST160F--1110105 Governor Cover 1
28 ST168F--1080200 Side Place 1
29 ST160F--1030003 Drain Plug Bolt 2
30 ST160F--1030004 Drain Bolt Washer 2
31 ST168F-1030012-G Crankcase (for USA) 1
32 168 .120700 .00 Change Wire,Flameout 1
33 ST160F-1126000 Diode Comp 1
34 ST160F-1127000-A Oil Level Switch Assy 1
35 GB5758 AM7×35 Flange Bolt 2
36 ST168F--1050100 Connecting Rod Comp 1
37 ST168F-1050001-Q Crankshaft Comp 1
38 GB/T—276--94 Radial Ball Bearing 6205 2
39 ST168F-1030008-G Case Over Packing (No Asbestos) 1
40 ST160F--1030001-B Oil Filler Cap Assembly 1
41 ST160F--1030002 Oil Filler Cap Packing 2
42 ST168F-1030007-5/16-G Crankcase Cover (For USA) 1
43 GB5789--86-FB8-32 Flange Bolt 8*32 6
44 ST160F--1030005-B Oil Filler Cap 1
45 ST168F--1110005 Throttle Return Spring 1
46 ST160F--1110003 Governor Arm 1
47 GB6177--86-N6 Nut M6 3
48 ST160F--1110001 Governor Arm Shaft 1
49 ST160F-1123000-G Ignition 1
50 GB5789--86-FB6-25 Flange Bolt 6*25 2
51 ST168F--1110006 Governor Rod 1
52 ST168F--1110007 Governor Spring 1
53 ST160F--1110004 Governor Arm Bolt 1
54 ST160F--1110008 Lock Pin 1
55 168 .111008 .01 Sheath,Grip 1
56 168 .111000 .30 Control Assembly 1
57 ST168F--1040013 Valve Lifter 2
58 ST168F-1030015-G Dowel Pin 9*14 2
59 ST168F--1041000 Camshaft Assembly 1
60 4X7 .5X19-GB1099-79 Key 1
61 ST168F--1050005 Piston 1
62 ST168F--1050003 Piston Pin 1
63 ST168F--1050004 Piston Pin Clip 2
64 ST168F--1050200 Oil Ring Comp 1
65 ST168F--1050006 Second Ring Set 1
66 ST168F--1050007 First Ring Set 1
67 ST168F--1030009-G Cylinder Head Gasket 1
# Part Number Description Qty
68 152FMD--1001007 Dowel Pin 10*16 2
69 ST168F--1040002 Intake Valve 1
70 ST168F--1040006 Exhaust Valve 1
71 ST168F--1080002-G Shroud Comp 1
72 F6RTC Spark Plug 1
73 GB5789--86-FB8-55 Flange Bolt 8*55 4
74 ST168F-1040014 Valve Oil Seal 2
75 ST160F--1040003 Valve Spring 2
76 ST160F--1040007 Exhaust Valve Spring Retainer 1
77 ST160F--1040001 Intake Valve Spring Retainer 1
78 ST160F--1040008 Valve Rotator 1
79 168 .040202 .34 Rocker Axes 1
80 ST160F--1040022 Entrance Rocker 1
81 ST160F--1040024 Rectify Bolt 2
82 ST168F--1040025 Lock Nut 2
83 GB97 .1 6 Washer 6 6
84 GB6183-86-M6 Nut M6 2
85 168 .040201 .34 Valve Rocker Arm 1
86 ST168F--1040027 Pivot Bolt 2
87 168 .040004 .34 Guide,Push Rod 1
88 ST168F--1040005 Push Rod 2
89 ST160F--1020002-A Head Over Packing 1
90 ST168F--1020100-C Head Over Comp 1
91 ST160F--1020001 Breather Tube 1
92 GB5789--86-FB6-15 Flange Bolt M6*15 4
93 ST160F-1010002 Stud Bolt 2
94 ST168F-1100200-G Muffler Packing (No Asbestos) 1
95 GB16674 M5×10 Screw M5×8 4
96 GB848-85-W5 Washer 5 4
97 GB859-87-SW5 Spring Washer 5 4
98 168 .101200 .34 Muffler Protector(Chromeplate) 1
99 188 .101300 .34 Arrester,Spark 1
100 GB818 M4×6 Bolt M4x6 4
101 168 .101100 .34 Muffler Comp 1
102 GB6170--86-N8 Nut M8 2
103 GB848-85-W8 Washer 8 2
104 GB859-87-SW8 Spring Washer 8 2
105 ST168F--1010100-G Cylinder Head Comp 1
106 ST160F--1010001 Stud Bolt 6*113 2
107 ST160F--1130002-CPE Insulator Packing (No Asbestos) 1
108 ST168F--1130001 Carburetor Insulator 1
109 ST160F--1130003-CPE Carburetor Packing (No Asbestos) 1
110 ST168F-1130000-G Carburetor Assembly 1
111 ST160F--1130100 Choke Level Comp 1
112 ST160F--1130004 Carburetor Washer 1
113 168 .091100 .34 Air Cleaner Elbow Comp 1
114 GB5789--86-FB6-20 Flange Bolt M6*20 4
115 168 .091003 .34 Air Cleaner Element 1
116 168 .091200 .34 Air Cleaner Cover 1
117 ST168F-1090100-C Air Cleaner Cover Nut (Plastic) 2
118 ST160F--1070100H Fuel Tank Cap Comp 1
119 ST160F-1070006 Fuel Filter 1
120 GB5789--86-FB6-29 Flange Bolt M6*29 1
121 GB859-87-SW6 Spring Washer 6 4
122 168 .071000 .35 Fuel Tank Comp 1
123 ST152FD-1070200 Fuel Filter 1
124 ST1P68F-1070006-F Clip 1
125 ST168F-1070200-G Fuel Valve 1
126 ST168F-1070005-G Tube 2 1
127 168 .070010 .34 Fuel Tank Veil 1
128 21 .001000 .00 Switch 1
129 ST168F-1070003-G Fuel Valve Knob 1
130 GB818-88-B4-12 Bolt M4x12 1
131 GB16674--1-FB5-12 Flange Bolt M5*12 1
132 ST188FD--1070006A Clip 8 3
133 ST168F-1070004-G Tube 1 1
