Headlamps, Front Turn Signal,
Sidemarker, and Parking Lamps
1. Open the hood. See Hood Release on page 5-9 for
more information.
2. Push in on the
headlamp panel and
lift up the headlamp
retaining clip partway,
but do not remove.
3. Remove the wing stud on the upper, outboard side
of the lamp assembly.
4. Unsnap the headlamp assembly by pulling it
forward, away from the vehicle.
5. Disconnect the electrical connector by pulling
back on the locking tab, located on the electrical
connector, to separate the two connectors.
6. Turn the bulb socket
one-quarter of a turn
clockwise.
7. Pull the bulb assembly out from the lamp housing.
5-45
