N2400329, 11/11, Rev. 0 260750 Operating Instructions
4.7.3 Remove the Carousel Plate from the rotator and adjust the angle as desired.
4.7.4 Re-install the Carousel plate onto the mini-tube rotator and install sample tubes into carousel
making sure that the tubes are balanced in the carousel.
4.7.5 Turn the rotator on by depressing the power button on the control panel.
4.8 Changing Carousel plate
4.8.1 Turn off the mini-tube rotator by depressing the power button on the instrument control panel
4.8.2
Gently Remove the Carousel and select the desired Carousel to be used on the Mini-Tube
Rotator housing.
4.8.3
Re-install the Carousel plate onto the mini-tube rotator and install sample tubes into
carousel making sure that the tubes are balanced in the carousel.
4.8.4
Turn on the power by depressing the Power Button on the front of the control panel.
5. Specifications
• The Boekel Scientific Mini-Tube Rotator provides:
o Digital Microprocessor Control.
o Cold Room and incubator compatibility.
o Adjustable speed provides gentle or vigorous mixing action.
o Adjustable angled carousel offers various mixing angles.
o Three Carousel options provide greater versatility for most tube mixing needs.
o AC Adapter is UL, CSA, and CE approved
o 2 Year warranty
• Speed range ………………….…………...........…......................................Variable 4 to 18 rpm
• Carousel angle ………………….................................................................................Variable
• Carousel Capacity
Re-order Number
36 x 1.5/2.0 ml Tubes 260751
10 x 10/15ml Tubes and 16 x 5/7 ml Tubes 260752
6 x 50 ml Tubes 260753
• Carousel Load Capacity.................................................................................0.8 Kg (1.75lbs)
• Dimensions (W x D x H)……………………22.9 cm x 12.7 cm x 15.24 cm (9 in. x 5 in. x 6 in.)
• Weight………………………………………………………………..…………………..2 kg (4.5 lbs)
• Power….…………………………………….….....12 Volt DC, 1.0A via 100/240 Volt AC Adaptor
