6
6. Technical Specifications
Operating Temperature Range
20⁰C to 30⁰C
Settable Temperature Range 40.0⁰C to 75⁰C
Temperature Accuracy ±2.0⁰C
Reservoir Capacity 5.0 Liters
Electrical Model # 145600
Model # 145600-2
115VAC 50/60hz 250W
230VAC 50/60hz 250W
Approvals Model # 145600
Model # 145600-2
Certified to UL 61010-1 and CSA C22.2
CE Certified
7. Maintenance and Service
The reservoir screen in the bottom of the reservoir should be checked and
cleaned periodically.
7.1 Cleaning
Disengage power cord prior to cleaning. Paraffin build-up should be
avoided around the top area of the Wax Dispenser. The outer casing
may be cleaned with water and a damp cloth. Do not submerge or
immerse the Wax Dispenser in water. Before using any cleaning or
decontamination method, users should verify that the proposed method
would not damage the equipment.
7.2 Replacement of Fuses
There are two supply fuses located in the fuse drawer. To replace the
fuses:
• Disconnect the unit from the power supply.
• Remove the plug from the socket in the back of the unit.
• Pull back on the fuse drawer (see figure 2)
• Pull out the fuse drawer
• Check and replace with the correct fuses if necessary. The fuses
must be 5 mm x 20 mm fast acting, rated 4A and 250V.
• Push the fuse drawer back in. Reconnect unit to the power
supply.
Fuse
Drawer
Figure 2
