40
R2-Series User’s Manual 11/13/12
MKTF - 212
R2-6140 SYSTEM PART LIST
Item No. Quantity Part Number Description
1 1 206422
PUMP, MULTISTAGE, 5HP,208-
230/460V,3HP,TEFC,3SV26PB30/V10742A
2 1 204914 VALVE, SOLENOID, N/C, UL, 220V, 1” FNPT, 3 METER CORD
3 1 205098 SWITCH, PRESSURE, HIGH, N/C 450PSI, ¼” MNPT, NASON
4 1 205903 VALVE, GLOBE, 316, 1" FNPT, 800LB
5 2 205113 VALVE, BALL, REDUCED PORT, ¾” FNPT, 316SS
6 1 203649 HOUSING, FILTER, BLK/BLU, 4.5”x 20”, 1” FNPT
7 1 200640 CARTRIDGE, SEDIMENT, POLYPRO, 4.5" X 20", 5 MIC
8 1 205097 SWITCH, PRESSURE, LOW, N/O 5PSI, ¼” MNPT, NASON
9 1 205589
HOUSING, MEMBRANE, 450PSI, FRP, 4040, 1" VICTAULIC,
P-18, ROPV
10 1 205593
HOUSING, MEMBRANE, 450PSI, FRP, 4040, 1" VICTAULIC,
P-46, ROPV
11 1 205591
HOUSING, MEMBRANE, 450PSI, FRP, 4040, 1" VICTAULIC,
P-27, ROPV
12 1 205589
HOUSING, MEMBRANE, 450PSI, FRP, 4040, 1" VICTAULIC,
P-18, ROPV
13 1 205593
HOUSING, MEMBRANE, 450PSI, FRP, 4040, 1" VICTAULIC,
P-46, ROPV
14 1 205591
HOUSING, MEMBRANE, 450PSI, FRP, 4040, 1" VICTAULIC,
P-27, ROPV
15 1 203263
CONTROLLER, COMPUTER, ROTROL S-150, 220V, 3PH, 5
HP
16 1 200899 METER, FLOW, PM, 0-10 GPM, 1” MNPT x 1” MNPT
17 1 200899 METER, FLOW, PM, 0-10 GPM, 1” MNPT x 1” MNPT
18 1 200965 VALVE, CHECK, PP, 1/2" FNPT X 1/2" FNPT
19 2 205099 GAUGE, BKM, FILL, 0-100PSI/BAR, 2.5” DIA, ¼” MNPT, SS
20 2 205100 GAUGE, BKM, FILL, 0-600PSI/BAR, 2.5” DIA, ¼” MNPT, SS
21 6 205949 MEMBRANE, LC LE, 4040, FILMTEC
22 1 203296 VALVE, NEEDLE, SS 316L, 3/4" FNPT
R2-1140 FLOW DIAGRAM
