NUMBER IDENTIFICATION
1.
SOLENOID VALVE – TURNS FEED WATER ON/OFF
2.
5 MICRON SEDIMENT – REDUCES PARTICULATES
3.
PRESSURE GAUGE – MEASURES FEED PRESSURE
4.
PRESSURE GAUGE – MEASURES PRESSURE AFTER FILTER
5.
PRESSURE GAUGE – MEASURES PUMP PRESSURE
6.
PRESSURE GAUGE – MEASURES CONCENTRATE PRESSURE
7.
COMPUTER CONTROLLER – CONTROLS RO SYSTEM FUNCTIONS
8.
CONCENTRATE VALVE– CONTROLS FLOW OF CONCENTRATE (WASTE) WATER
9.
RO PUMP AND MOTOR – PRESSURIZES RO SYSTEM
10.
THROTTLE VALVE – CONTROLS FLOW OF PUMP
11.
FLOW METER – MEASURES FLOW OF PERMEATE WATER
12.
FLOW METER – MEASURES FLOW OF CONCENTRATE (WASTE) WATER
13.
LOW PRESSURE SWITCH – TURNS OFF RO PUMP WHEN FEED PRESSURE FALLS BELOW
SET POINT
14.
PERMEATE CHECK VALVE – PROTECTS MEMBRANE ELEMENTS FROM BACKPRESSURE
15.
PRESSURE VESSELS – HOUSES MEMBRANE ELEMENTS
16. HIGH PRESSURE SWITCH – TURNS THE PUMP OFF AT A PRE-DETERMINED HIGH PSI PUMP
PRESSURE
17.
PERMEATE SAMPLE VALVE- MEASURES THE QUALITY OF EACH MEMBRANE
18.
CLEANING PORT VALVE- PROVIDES ACESS TO CLEAN THE MEMBRANES
