AvMap EKP V Installation Guide - Manual (Page 6)

Aeronautical Products EKP V Docking Station
6 - Installation Guide
Aeronautical Products EKP V Docking Station
Installation Guide - 7
Back Side
D Battery powered USB Port: backup power provided by the EKP V internal battery.
E Normal USB Ports: powered by the aircraft electrical system.
F DB 15 direct soldering connector (OEM version only).
G Wire clamp connector (Standard version only).
H Cable locking bar.
Back Side - Standard Version
D
E
F
Back Side - OEM Version
D
E
G
H
