AvMap EKP V Installation Guide - Manual (Page 4)

Aeronautical Products EKP V Docking Station
4 - Installation Guide
Aeronautical Products EKP V Docking Station
Installation Guide - 5
General Description
The EKP V Cockpit Docking Station (CDS) allows the installation of AvMap EKP V
Aeronautical Navigator into the cockpit, and enables the unit to interface to multiple external
devices at the same time.
When docked the EKP V is powered/charged by the aircraft electrical system.
A2 ADAHRS
Module
Autopilot
External
GPS
Traffic
Receiver
XM WX Weather
Receiver
CONNECTIVITY
Cockpit integration with
Docking Station
