AOC E1759FWU - Manual (Page 24)

24
Specification
General Specification
Panel
Model name E1759FWU
Driving system TFT Color LCD
Viewable Image Size 43.8cm diagonal
Pixel pitch 0.2388(H)mm x 0.2388(V)mm
Display Color 262144 Colors
Dot Clock 107.80MHz
Resolution
Horizontal scan range 55.567kHz
Horizontal scan
Size(Maximum)
382.08mm
Vertical scan range 60Hz
Vertical scan
Size(Maximum)
214.92mm
Optimal preset
resolution
1600×900@60Hz
Plug & Play VESA DDC2B
Input Connector Micro USB 3.0
Input Video Signal NA
Power Source PC USB 5V
Power Consumption
10 W
Standby < 0.5 W
Off timer NA
Physical
Characteristics
Connector Type Micro USB 3.0
Signal Cable Type Detachable
Dimensions & Weight:
Height
250 mm
Width 412 mm
Depth 18 mm
Weight (monitor only) 1280 g
Environmental
Temperature:
Operating
0° to 40°
Non-Operating -25°to 55°
Humidity:
Operating
10% to 85% (non-condensing)
Non-Operating 5% to 93% (non-condensing)
Altitude:
Operating
0~ 3658m (0~ 12000 ft )
Non-Operating 0~ 12192m (0~ 40000 ft )
