AOC 193FWK - Manual

TECHNICAL SPECIFICATIONS
• Cabinet Color: Black
• Panel: TFT Active Matrix LCD, VIS: 19" (48.2 cm) Widescreen, Diagonal, Hard Coating (3H),
Anti-glare Treatment
• Pixel Pitch: 0.285 mm x 0.285 mm
• Display Area: 410 mm x 256 mm
• Brightness: 300 cd/m² (typ)
• Contrast Ratio: 500:1 (typ)
• Response Time: 8 ms (typ)
• Viewing Angle: Horizontal: 160 Degrees (CR>5) Vertical: 135 Degrees (CR>5)
• Compatibility: VESA, WXGA+, SXGA, XGA, SVGA,VGA, Mac® Equipped With VGA Port
• Scanning Frequency: Horizontal: 30 K ~ 80 KHz, Vertical: 55 ~ 75 Hz
• Pixel Frequency: 135 MHz
• Maximum Resolution: 1440 x 900 x 60 Hz
• Recommended Resolution: 1440 x 900 @ 60 Hz
• Resolutions Supported: 720 x 400 @ 70 Hz, 640 x 480 @ 60, 66, 72, 75 Hz, 800 x 600 @ 56, 60, 72, 75 Hz,
832 x 624 x 74.5 Hz, 1024 x 768 @ 60, 70, 74.7, 75 Hz, 1152 x 864 x 75 Hz, 1280 x 1024 @ 60, 75 Hz
• Color: 16 M
• Signal Input: Video: 0.7Vp-p, RGB Analog, Separate Sync: TTL Level, H/V Sync: Positive / Negative
• Digital Input: DVI (TMDS)
• Connectors: Analog RGB Signal: 15-pin D-sub Male, DVI-D: 24-pin DVI-D, Power: Coax Power Jack
• Power Source: Universal 100 ~ 240 VAC, 50/60 Hz (via External Power Brick)
• Power Consumption: 50 Watts (Max)
• Plug & Play: DDC2B
• EPA ENERGY STAR®: Yes
• User Control: Auto, Brightness/Down, Contrast/Up, Menu, Power
• OSD Function: Contrast, Brightness, Focus, Clock, H-Position, V-Position, Color, Temperature,
Auto-Config, OSD Position, OSD, Timeout, Language, Information, Reset, Exit
• OSD Languages: English, French, Spanish, Portuguese, German, Chinese
• Regulations: cULus, FCC, TUV/GS, CE, ISO 13406-2, Windows® XP Logo
• Other Features: VESA 75 mm Wall Mount Compliant*, Kensington Security Slot
• Dimensions (W x H x D mm): Monitor: 440 x 359 x 201; Carton 510 x 425 x 145
• Dimensions (W x H x D inches): Monitor: 17.3 x 14.1.9 x 7.9; Carton 20.1 x 16.7 x 5.7
• Monitor Dimensions w/o Base (W x H x D): 440 x 288 x 47 mm; 17.3 x 11.3 x 1.9 inches
• Weight: 8.8 lbs (4.0 kg) Net, 11 lbs (5.0 kg) Gross
• Loading Qty w/pallet: 20' = 825 pcs.; 40' Std = 1725 pcs.
• Warranty: 3 Years
Monitor LCD 19” (193FWk)
UPC Code 685417006083
Note: Specifications are subject to change without notice.
*Wall mount arm & bracket not included.
