SPECIFICATIONS
A2272PW4T
LCD Panel
Driving system
21.5” WLED
Size
54.7cm diagonal
Pixel Pitch
0.24825mm(H) × 0.24825mm(V)
Input
Video
R, G, B Analog Interface
Digital
Separate Sync.
H/V TTL
H-Frequency
30kHz ~ 83kHz
V-Frequency
50 ~ 76Hz
Display Colors
16.7M Colors
Dot Clock
148.5MHz
Max. Resolution
1920×1080@60Hz
Plug & Play
VESA DDC2B™
LAN Speed
10/100Mbps
RF Module M/N
BCM94330LGA
Built-in Webcam
1.0 megapixel camera with microphone and LED indicator
Power Consumption
ON Mode
30W (Typ.)
Standby Mode
≤ 2W (VGA/HDMI)
OFF Mode
≤ 0.5W
Input Connector
D-Sub 15pin
HDMI 19pin
Input Video Signal
Analog: 0.7Vp-p(standard), 75 OHM, positive or negative
HDMI: 0.7Vp-p(standard), 75 OHM, positive or negative
Power Source
100~240VAC, 50/60Hz
Environmental Considerations
Operating Temp.: 0° to 40°C
Storage Temp.: -20° to 60°C
Operating Humidity: 15% to 90%
Dimensions
561.93(W) x 355(H) x 47.1(D) mm
Weight (N. W.):
5.0 kg
